Technische Details
PANEL
Screen Size: 55"
Panel Technology: IPS
Contrast Ratio: 1,100:1
Response Time: 12 ms (G to G BW), 9.0 ms (WOT)
Brightness: 450 nits
Native Resolution: 1,920 x 1,080 (FHD)
Viewing Angle (H x V): 178°/178°
Orientation: Landscape & Portrait
Lifetime (Typ.): 50,000 Hrs
Operation Hours: 24 Hrs
Surface Treatment (Haze): Hard Coating (3H), Anti-glare Treatment of the Front Polarizer (Haze 1% (Typ.))
CONNECTIVITY
Input: HDMI (3), DP, DVI-D, Audio, USB 3.0
Output: DP (SST), Audio (Off/Fixed/Variable)
External Control: RS232C In/out, RJ45 In, IR Receiver In
PHYSICAL SPECIFICATIONS
Bezel Width: 11.9 mm (T/R/L), 18 mm (B)
Monitor Dimension (W x H x D): 48.7 x 28.4 x 2.1 / 1,238 x 714.9 x 54 mm
Weight (Head): 38.6 lbs / 17.5 kg
Monitor w/opt. Stand Dimensions (W x H x D): 48.7 x 30.4 x 8.6 / 1,238m x 773.4 x 219.6 mm
Weight (Head + Stand): 45.9 lbs / 20.8 kg
Carton Dimensions (W x H x D): 52.4 x 31.8 x 6.7 / 1,330 x 807 x 170 mm
Packed Weight: 47.8 lbs / 21.7 kg
VESA: 300mm x 300mm
KEY FEATURES
Internal Memory 8GB (System 4GB, Available 3.6GB), Built-in Wi-Fi, Temperature Sensor, Auto Brightness Sensor, Current Sensor, webOS 4.0, Embedded CMS, Fail Over, Image Customization, PIP/PBP(2), Screen Share, Video Tag (2), Play via URL, Gapless Playback, Tile Mode Setting (Up to 15x15), Setting Data Cloning, Firmware Update by Network, SNMP (Ver. 1.4), Control Manager, Crestron Connected®*, Extron IP Link, Smart Energy Saving, Beacon, HDMI-CEC (2)**, Built-in Speaker (10W+10W)
ENVIRONMENTAL CONDITIONS
Operating Temperature Range: 0°C to 40°C / 32°F to 104°F
Operating Humidity Range: 10 % to 80 %
POWER
Power Supply: 100-240V~, 50/60Hz
Power Type: Built-In Power
Power Consumption (Smart Energy Saving): 70 W (TBD)
Power Consumption (Typ./Max): 100 W (TBD) / 115 W
STANDARD CERTIFICATIONS
Safety: IEC 60950-1 / EN 60950-1 / UL 60950-1
EMC: FCC Class "A" / CE / KCC
MEDIA PLAYER COMPATIBILITY
External Media Player Attatchable: Yes
OPS Type Compatible: Yes
SOFTWARE COMPATIBILITY
Content Management Software: SuperSign CMS
Control and Monitoring Software: SuperSign Control+/Control
ACCESSORIES
Basic: Remote Controller (2ea Batteries Included), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender, Memory Cover
Optional: Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA), HDBaseT (EB-B100), Touch Overlay (KT-T49E)
